154409001 Dishwasher Control Board Repair
154409001 Dishwasher Control Board Repair
SKU: 13421

154409001 Dishwasher Control Board Repair

Our services are fast and easy. Send us your failed dishwasher control circuit board. We will quickly repair your dishwasher control circuit board. We do more than just repair the part, we go to the root of the problem and use the high quality parts to ensure the issue does not return.
  • Estimated Repair Time is 3-5 business days.
  • 2 Year Warranty
  • Real-Time Repair Tracking
  • Our service is 100% guaranteed or your money back. Order today and save!
  • International Shipping Available
  • Free shipping available at online checkout!
$159.99
$179.99
Save: 11%
Repair yours
Send your original part for repair service
$159.99
$179.99
Save: 11%
Service Price:
Options Price:
Total:
In-stock item
Send me a good working part
Description

Description

This is a repair service for 154409001 Dishwasher Control Board Repair.
For the following brands: Frigidaire, Gibson, Kenmore

This repair is also for the following similar dishwasher control board part numbers:
154367901, 154409001.

Why Repairing with UpFix is the Better Choice

  1. Cost-Effective: Avoid the high cost of full appliance replacement. Repairing your control board with us can save you substantial amounts of money, preserving your appliances functionality without breaking the bank.
  2. Time-Efficient: Choosing to repair rather than replace can drastically reduce the downtime of your appliance. UpFix aims to restore your kitchen’s functionality quickly, eliminating the hassle of searching and waiting for new parts.
  3. Eco-Friendly: Repairing your appliance with UpFix is a step towards sustainability. By refurbishing your existing control board, you help reduce electronic waste and conserve natural resources, supporting environmental conservation efforts.

Our Expert Repair Process

When you send your defective control board to UpFix, it receives more than just a repair. Our technicians conduct a comprehensive diagnostic to identify and rectify faults. We replace not only the failing components but also upgrade other elements known to degrade over time, ensuring your control board returns to you in top condition.

How It Works


Once we receive your part, our trained and IPC certified technicians will run tests to identify the source of the problem. We will rebuild your part, replacing not only the failed components, but all components that are usually known to fail or go bad in this part. We want to make your experience as effortless as possible. All you have to do is send your part to us. Then after receiving the part back from us, just reinstall it and you’re back in business!

Wide Coverage

Our services are designed to accommodate a multitude of part numbers and models, enhancing the accessibility of our expert repairs across different brands.

What to Expect from UpFix

  • Mail your faulty part to us.
  • Our experts will rebuild and rigorously test your control board.
  • Receive your like-new control board, reinstall it, and enjoy your fully functional appliance once again.

Added Benefits of Choosing UpFix

  • Estimated Repair Time is 3-5 business days.

  • International shipping options to the USA and Canada.
  • Comprehensive testing post-repair to guarantee performance.
  • A 24-month warranty and lifetime phone support, underlining our commitment to quality and customer satisfaction.
  • We uphold the highest standards of integrity and community support in all our business practices.

Removal Instructions

154409001 Dishwasher Control Board Repair

  1. Turn off breaker.
  2. Unplug your unit from the outlet.
  3. Take pictures of each step of the removal process to ensure all wires are correctly reinstalled. Failure to do so may cause severe damage or fires. Failure to reinstall correctly will void all warranties.
  4. Remove the part that needs to be repaired.
  5. Start your order today!
  6. We will provide you with a shipping label at checkout.

We take pride in our work and will take it a step further and fully inspect your control board and will replace failure prone components or parts that may be failing in the future. Each control board is fully tested to make sure it passes a full functional test.

Our service is 100 percent guaranteed or your money back. We stand by our services – If the part is going to fail, itll fail within the first 24 months. Thats why we got you covered with a 24-month warranty and lifetime phone support when you need us

Our goal is to save you hundreds of dollars, while continuing to provide an eco-friendly solution that reduces pollution. We drive our business towards consistent and profitable growth, with integrity and a commitment to the people and communities where we live and work. Our service is 100% guaranteed or your money back.



This repair service will fix these issues:

  • Constant heating
  • Dead circuit board
  • Dim/Dark Display
  • Dim/Dark Lights
  • Does not Cycle
  • Failed after power outage
  • Intermittent failures
  • Intermittent operation
  • LCD Display
  • No power
  • No power to heating element
  • No power to pump
  • Non-Responsive
  • Pump runs continuously

Will this service fix my problems?

A full diagnostic check should first be performed to eliminate all other possible causes for your symptoms, even if the symptoms match those specified on the common fault description.

If you send a unit in good working condition due to misdiagnosis, and our testing determines that there are no issues or faults with the unit, or if the part is beyond repair, then you will only be responsible for the shipping costs and a bench test fee of $39.99 may be applied.

IMPORTANT! If you are not sure that this part is the cause of the fault then we recommend that you do not go ahead with this purchase and instead seek further professional advice and diagnosis.


See Why Our Customers Love UpFix!





Benefits of using us:
  • Free return trip shipping
  • Save hundreds of dollars
  • High quality components
  • Fast & easy process
  • 100% guaranteed or your money back
  • Amazing customer service and support
  • IPC certified technicians (highest standard of quality craftsmanship)
  • Guaranteed OEM products
  • Refurbished and tested to meet manufacturers specifications
  • Hassle-free warranty that is much better than the warranties you get for new replacements.
How It Works

How It Works

Our services are fast and easy. Send us your failed part. We do more than just repair the part, we go to the root of the problem and use the best quality parts to ensure the issue does not return.

We take pride in our work and will take it a step further and fully inspect your control board and will replace failure prone components or parts that may be failing in the future. Each control board is fully tested to make sure it passes a full functional test. Our service is 100 percent guaranteed or your money back.


  1. Locate your product on our website.
  2. Match your symptoms with our descriptions to diagnose the issue.
  3. Place a repair order and receive a shipping label.
  4. Send your item to us.
  5. We'll repair and promptly ship it back to you!
Warranty

Warranty

Our service is 100 percent guaranteed or your money back.

For a full 24 months, our no-hassle warranty covers the repair. We will fix the item again if the repair fails within 24 months. If the component is not repairable, we will, at our discretion, either replace the part entirely or refund the cost of the repair.

We stand by our services – If the part is going to fail, itll fail within the first 3 months. Thats why we got you covered with a 24-month warranty and lifetime phone support when you need us

Part Numbers

154409001, 154367901

Error Codes
CodeDescriptionRecommended Action
CEConfiguration errorThis error suggests a communication issue between the keypad and the control board. It’s usually an electronic issue that will require a professional.
CLClose door or door switch open This can mean that the door is not closed properly, or that there’s an issue with the door switch assembly.
dPDrain pump activated (relay test) This code will only show up during diagnostic testing, indicating an issue with the drain pump.
ERMembrane switch failure/stuck keysThis suggests one or more of the keys in the control pad are stuck. Try massaging each button to unstick; otherwise, the keypad may need replacing.
FLWater valve open (relay test) This code will also only show up during diagnostic testing, meaning the water valve is not closed properly.
HOHeat delay or low water temperature This code means your dishwasher is taking longer than it should to reach the necessary temperature. Make sure the water heater is set to the correct temperature, and check to ensure the hot water in your house is working correctly.
HsHall sensor errorThis indicates an issue with the hall sensor, which may affect the motor.
i10Abnormally low water level This error usually indicates a problem with the water supply line. It could indicate a leak, so check to see if water is pooling underneath your dishwasher. It’s also a good idea to check if the supply line is properly turned on and to check for any kinks.
i20, i40, iFoDrain line restrictedThese error codes all relate to drainage issues. It could mean the drain hose is kinked or clogged, or the dishwasher’s filter is blocked and restricting water flow. Clearing blockages should resolve this error.
i30Leak in bottom panThis means that water has been detected in the bottom pan, indicating a leak. Check for pooling water and around the hose connections to make sure water isn’t escaping.
i50Drain or wash motor failure This issue means that either the drain or wash motor is not working properly, which means water can’t circulate and drain correctly. Blockages in the system can cause this, but you may need to call in a professional.
i60Water heating system problemThis suggests an issue with your dishwasher’s water heating system. There may be an issue with the heating element or even the control board. In most cases, this issue will require professional assistance to resolve.
iCoElectronic control system failureThis indicates a serious issue with the electronic system. Try a hard reset: unplug your Frigidaire dishwasher for five minutes and then plug it back in. If this doesn’t solve it, you may need to call in a professional.
LOLow rinse aidThis code means that the rinse aid in your dispenser is running low. To clear the error, all you have to do is refill the dispenser!
PFPower failureThis is probably the most common code you’ll come across. The PF stands for power failure, which means that the dishwasher’s power supply has been interrupted during the cycle. This could be due to a power surge or power outage, the circuit breaker tripping, or even due to the power cord being bumped. If you’re seeing the error, obviously power has been returned to your dishwasher, or the display wouldn’t be working! To clear the code, try opening and closing your dishwasher to clear the error code, then use it as normal. If this code keeps recurring, it could indicate a voltage issue that you will need a professional to look at.
rARinse aid reed switch failure This error means that the reed switch in the rinse aid dispenser isn’t working. Your dispenser may need to be replaced.
RtRelay/triac testThis code will only show up during testing, meaning the dishwasher has been placed into test mode. If this happens accidentally, try a hard reset to clear it.
TuTurbidity sensor failure This code means that the turbidity sensor has failed. The turbidity sensor is used to monitor water clarity in your dishwasher to ensure the dishes are properly cleaned. If this happens, you may need to replace the sensor.
UFVent failure or fan not runningThis code is similar to UO but indicates that the vent fan is the issue. The fan may need replacing to ensure the dishes can dry properly.
ULUL test activated Another code that appears during testing. If you didn’t activate this code on purpose, try a hard reset to fix the issue.
UOVent openThis means that the vent is not properly closed. Check the vent assembly to ensure it’s working correctly, or seek professional help.
Models

This control board may be found in models similar to the following:

58715162400, 58715162401, 58715163400, 58715163401, 58715163402, 58715164400, 58715164401, 58715169400, 58715169401, 58716162400, 58716162401, 58716163400, 58716163401, 58716163402, 58716164400, 58716164401, 58716169400, 58716169401, FDB658RAC1, FDB780RCB0, FDB780RCQ0, FDB780RCS0, FDBC56BAB0, FDBC56BAB1, FDBC56BAS0, FDBC56BAS1, GDB754RCB0, GDB754RCQ0, GDB754RCS0, GDB755RJB2, GDB755RJD2, GDB755RJQ0, GDB755RJQ1, GDB755RJS2, GLDB756AB1, GLDB756AQ1, GLDB756AS1
